Product Details:
|
| Material: | Aluminum | Color: | Slive |
|---|---|---|---|
| Voltage: | 12v,24v,110v,220v | Application: | Air Boat Application |
| Flowrate: | 15L/M | Pressure: | 30KPA |
| High Light: | micro electric air pump,micro pressure pump |
||
Air Boat miniature air pumps / Electromagnetic Pump , 50HZ or 60HZ
The air pump can be made into AC220V AC110V AC24V AC12V or DC model, when you need one excellent air pump to work for your air boart, please tell us your requirements, we will give you suitable one.
Quick Detail:
| Place of Origin: | Zhejiang China (Mainland) | Brand Name: | Cinh or Blank | Model Number: | QBF-15 |
| Theory: | Electromagnetic Pump | Structure: | Diaphragm Air Pump | Usage: | Air Pump |
| Power: | Electric | Flowrate: | 15L/m | Fuel: | Electric |
| Pressure: | 30KPA | Application: | pressing air |
Specifications:
| ITEM | SPECIFICATION |
| Air Output: | 30SCFH(15Lpm) |
| Pump Pressure: | 4.5PSI(30kpa) |
| Power Requirement: | AC220V,AC120V, AC24V or AC12V, 50Hz or 60Hz |
| Power Consumption: | 10W |
| Pump Design: | Double diaphragm, duckbill valves |
| Pump Body: | Aluminium |
| Outlet & Inlet Dia: | 0.3"(7.6mm) |
| Electrical Connections: | 1-ft(300mm)Insulated wire pair |
| Noise Level: | 40db unconnected, connected operation will reduce db level |
| Dimension(LxWxH): | 4.2"x3"x2.9"(106x76x74mm) |
| Net Weight: | 0.62kgs |
Applications:
medical applications
industrial applications
compression therapy
ozone generator
aquarium
recovery system
fragrance diffuser
air bed
Atmospheric Detection
Dosing chemical material
air cloth
balloon
medical
humidifier
blood pressure
gas monitor
dosing
cooling system
ink
water heater
boiler
boat
gas boiler
breast
fridge
pillow and mattress
Performance Curve
