High Performance Long Lifetime Rotary Vane Vacuum Pump Max Pressure 90Kpa

China High Performance Long Lifetime Rotary Vane Vacuum Pump Max Pressure 90Kpa supplier
High Performance Long Lifetime Rotary Vane Vacuum Pump Max Pressure 90Kpa supplier High Performance Long Lifetime Rotary Vane Vacuum Pump Max Pressure 90Kpa supplier

Large Image :  High Performance Long Lifetime Rotary Vane Vacuum Pump Max Pressure 90Kpa

Product Details:

Place of Origin: China
Brand Name: no brand or Cinh
Certification: ROHS
Model Number: PBW12

Payment & Shipping Terms:

Minimum Order Quantity: 210pcs
Price: Negotiable
Packaging Details: Carton+ white box+ plastic film
Delivery Time: 3 to 35days
Payment Terms: T/T or L/C
Supply Ability: 5000pcs each day
Contact Now
Detailed Product Description
Model: PBW12 Type: Brushless DC Micro Vacuum Pump
Rated Voltage: DC12V, DC24V Flowrate: 1.3L/m Air, 320ml/m Water
Pressure: 90kPA, Suck 2m Height Consumption Current: 250mA
Max Pressure: More Than 90 KPa Endurance Time: More Than 8000 Hours
Application: Aquarium, Medical, Dosing, Atmospheric Detection



High Performance Long Lifetime Brushless DC Micro Vacuum Pump ,  90kpa ​


Quick Detail:

Brushless DC micro vacuum pump
1. Brushless motor, super long lifetime, super quiet
2. More than 320+_50mL/m for water flowrate, can work with water or wine or oil or ozonized water flowrate or Ammonia gas or liquid. Water suctionable height 2m..
3. Speed adjustable and controllable with square wave signal
4. Corrosive resistance advanced pump film, can carry chemical liquid.
5. lifetime more than 8000hours continuously working day and night
6. size is ∮27x59.7mm
7. Outlet & Inlet Dia: 4mm
8. weight: 60g


Specifications:


ModelPBW12
TypeBrushless DC micro vacuum pump
Rated VoltageDC12V, DC24V
Flowrate320+_50mL/m for water flowrate
Consumption current250mA
Max pressuremore than 90 kPa
Coil insulation classficationA type
Endurance timemore than 8000 hours
Operating noiseLess than 20dB
Starting voltage8V
Weight60g
Operating Environmental Humidity0-90%RH



Description:

CINH Brushless DC micro vacuum pump PBW12 use a DC brushless motor design that has the capability of over 80000 hours of continuous maintenance-free operation. It is compact, very quiet, highly reliable and inexpensive, it has the design ability to work for chemical liquid or chemical gas continuously operating day and night.


Features


  • Dedicated Motor Matching
  • Wide range of voltage
  • Low level of noise
  • Low heat
  • Anti-electromagnetic interference
  • Long lifetime
  • Using dedicated industrial raw material, to ensure to continuous work long time under high and low temperature. even all kinds of bad condition.
  • Satisfy with customer’s special request with customized product



Applications:


Electric pumpselectronic blood pressure monitor
The monitorThe head massager
A tourniquetMassage goggles
Alcohol detectorThe coffee machine
Breathing machineAnalyzer
Ozone machineGas analyzer
Beautiful leg massagerTreadmill medical apparatus and instruments, etc.



 Operating principle

Miniature getter pump it works with the micro vacuum pump working principle is the same, all is the circular motion of the machine, by mechanical device inside the pump diaphragm do reciprocating motion, thus to fixed volume of air in the pump cavity vacuum (negative pressure), was formed by compression, stretching in the pump suction port atmosphere produces pressure difference with the outside world, under the action of pressure difference, the gas pressure (suction) into the pump chamber, then discharge from the vent.Because of bleeding point or smoke vent can atmospheric pressure difference with the outside world, and not like a big need lubricating oil vacuum pump and vacuum pump oil, not pollution of the working medium, and small volume, low noise, no maintenance, can be continuous 24 hours running, etc

High Performance Long Lifetime Rotary Vane Vacuum Pump Max Pressure 90Kpa
